Tilt Switch Sensor SW-200D SW200D Dual Ball Rolling

Detects tilt more than 15 degrees

Product Code 5862

Available We dispatch same day if ordered by 1PM (excluding holidays), then courier usually takes 2-5 days.

Real Time Availability

Ready Stock: 354 nos. Factory Leadtime for more quantity: 15 days.

If you order more than 354, We will send two packages, right now available stock and remaining in 15 days

Quantity: Price: Rs.12.00/-

Minimum: 10

Quantity Pricing

Quantity :

Price

1-49 :

Rs.12.00/-

50-99 :

Rs.11.40/-

100-499 :

Rs.10.80/-

500-999 :

Rs.10.56/-

1000+ :

Rs.10.20/-

Downloads

SW200D Datasheet

Tilt Switch Sensor SW-200D SW200D Dual Ball Rolling

Sunrom Product Code for Ordering:

5862

SW-200D is a dual ball type single direction tilt sensitive trigger switch. It is commonly used in automation devices. Hobbyists also use it on robotic chassis. When the device tilts to the conductive terminal (silver pin end - A) by more than 10 degrees, it will be at open circuit "OFF-state". When its horizontal postion changes, the trigger terminal (gold-pin end B) is below the horizontal tilt angle and more than 10 degrees, it will be at closed circuit "ON-state".

Features:

* Type: dual rolling ball
* Material: plastic / metal
* Shape: Round
* Color: black/white/gold
* Life span: 10,0000 cycles
* Contact Rating: Upto 5V/10mA
* Contact Resistance: 10ohm
* Insulation Resistance: >10M ohm min. at 24VDC
* Capacitance: 5pF
