CZN-15E Omnidirectional Electret Condenser Microphone 9x7mm with pins - 9767 - Capacitive - Sensitivity 58
Easy to mount on PCB due to pre-soldered pins, Low cost, Good quality, Distance between pins is 2.54mm
Product Code 5521
Available
We dispatch same day if ordered by 1PM (excluding holidays), then courier usually takes 2-5 days.
Real Time Availability
Ready Stock: 4509 nos.
Factory Leadtime for more quantity: 15 days.
If you order more than 4509, We will send two packages, right now available stock and remaining in 15 days
Quantity Pricing
Quantity :
Price
1-49 :
Rs.8.75/-
50-99 :
Rs.8.31/-
100-499 :
Rs.7.88/-
500-999 :
Rs.7.70/-
1000+ :
Rs.7.44/-
Downloads
CZN-15E MIC Datasheet
CZN-15E Omnidirectional Electret Condenser Microphone 9x7mm with pins - 9767 - Capacitive - Sensitivity 58
Sunrom Product Code for Ordering:
5521
Sensitivity: -58±2dB (0dB=1V/pa,1KHz)
Impedance: Low impedance
Directivity: Omnidirectional
Frequency: 20-16,000Hz
Voltage range: 1.5V-10V
Standard operation voltage:4.5V
Current consumption: Max.0.5mA
Sensitivity reduction: Within -3dB at 3V
S/N ratio: More than 60dB
