4 Channel Capacitive Touch Module - TTP224

Simple to use, Accurate, Output can be Active High or Low. Output mode can be ON/OFF(Toggle) or ON till touch(Momentary).

4 Channel Capacitive Touch Module - TTP224

Sunrom Part# 4632

Available We dispatch same day if ordered by 4PM (excluding holidays), then courier usually takes 2-5 days.
Real Time Availability
Ready Stock: 17 nos.
Factory Leadtime for more quantity: 15 days
Quantity Pricing
Quantity :
Price (Discount%)
1-4 :
Rs.300/- (0%)
5-9 :
Rs.291/- (3%)
10-24 :
Rs.279/- (7%)
25-49 :
Rs.270/- (10%)
50-74 :
Rs.264/- (12%)
75-99 :
Rs.255/- (15%)
100-249 :
Rs.246/- (18%)
250-499 :
Rs.240/- (20%)
500-999 :
Rs.234/- (22%)
1000+ :
Rs.225/- (25%)

This board is a quick demo board for capacitive touch sensing IC TTP224. You can use it to detect and switch on external units using external relay.

Features

  • Simple to Use, Auto Calibration
  • Output Status Indicator LED
  • Output can configured be Active High or Low
  • Output Mode can be configured to Toggle or Momentary
  • Easy to replace mechanical key outputs
  • Output can be directly connected to Microcontroller's Input pins

Specification

  • Operating Voltage: 2V-5.5V
  • Startup Calibration Delay: 0.5 Sec
  • PCB Size: 35x29mm

Board Schematic

Commercial Solid State solution using TTP224 IC to replace Dome, Membrane & Mechanical Keypads
